Features
- Optical peak power up to 15W
- Suited for short laser pulses from 1 to 200 ns
-
Design for Telcordia
Application
Distance Measurement,Laser Radar, Infrared Lighting, Traffic Surveillance
Parameter
| Item | Symbol | Min. | Typ. | Max. | Unit | Condition |
|---|---|---|---|---|---|---|
| Thresold Current | Ith | 0.5 | 0.75 | A | Tc=25℃ | |
| Power | Po | 13 | 15 | W | ||
| Operating Voltage | Vf | 9 | 12 | V |
Po=15w
|
|
| Wavelength | λc | 895 | 905 | 915 | nm | Po=15w |
